Flex Pro 2 Transmitter

The Flex Pro 2 series of radio remote controls offer even more features and greater performance than the first-generation Flex Pro. Flex Pro 2 transmitters are ergonomic, lightweight and are available in 4, 6, 8, and 12-button style options to meet your application needs.
Radio Application Questionnaire

Documents

Brochure
O&M Manual
Browse All Documents

Need Assistance?

Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.

Features and Benefits

Flexible, Customizable Design

  • Transmitters can be recharged in a convenient charging cradle without having to open for battery replacement
  • Optional battery cover enables tethered CAN communication via a 4-pin connector
  • Useful in situations when RF cannot be used because of RF jamming restrictions or when proportional control is needed but RF is not required
  • Can be kept on hand as a low-cost back-up to prevent delays

Innovative, Efficient Performance Features

  • Wireless IR pairing capabilities allow information and settings to be easily transferred between a transmitter/receiver system
  • Optional Radio Control Programmer (RCP) allows you to program settings from a Windows PC through a USB-C connector

Standard Models

  • Functions: 4, 6, 8, and 12 buttons
  • • 1, 2, and 3-step
  • • Proportional
  • Frequencies: Part 15 License Free, 433-434 MHz
  • Operating Range: Up to 100m (328 feet)
  • Diagnostics: On-board diagnostics with LED indicators for transmitter status
  • Operating Temperature: -13°F (-25°C) to 167°F (+75°C)
  • Battery Type:
  • • Two “AA” Alkaline non-rechargeable standard
  • • Two “AA” NiMH rechargeable optional

Comfortably Contoured and Durable

  • Enhanced optical proportional button technology improves transmitter reliability for more consistent system performance
  • Transmitters are rated NEMA 4 (IP66), sealed to withstand harsh indoor or outdoor environments
  • Useful in situations when RF cannot be used because of RF jamming restrictions or when proportional control is needed but RF is not required

Optional Features

Available with optional accessories, such as protective rubber transmitter boots, magnet mount, and a retractable belt clip, for added protection and flexibility.

IDEAL FOR THE FOLLOWING APPLICATIONS:

Documents

Brochures & Catalogs

[Brochure] Flex Pro 2 Brochure

Manuals & Supplements

[O&M Manual] IR Programmer Manual R6 [O&M Manual] Flex Pro2 Transmitter Instruction Manual [O&M Manual] Radio Control Programmer (RCP) Operating Manual

On the original Flex Pro transmitter, there was no option for use with rechargeable batteries. Is this an option available on the Flex Pro 2?

Yes, Flex Pro 2 can operate with both rechargeable and non-rechargeable batteries. There are battery contacts on the bottom of the transmitter that allow charging on a docking station. Plus, there are two docking station options for use on different types of applications, including the ability to be mounted directly on equipment for the mobile hydraulic market.



The Flex EX and Flex EM radio are offered with hazardous location certification options. Is the Flex Pro 2 going to be available with hazloc certifications?

No, initially Flex Pro 2 will not be offered with hazardous location certifications. The
hazardous location versions of both the Flex EX and Flex EM radios will continue to be
available for sale even once the standard versions of those radios become obsolete.



The original Flex Pro has a tethered option. Is there a Flex Pro 2 tethered option?

Yes, Flex Pro 2 offers a tethered option. A swappable battery allows users to change
between a tethered CAN communication via a 5-pin M12 B-coded connector and
wireless communication.
