CMLA-A Series - 500 Lbs
The CMLA-A Series 500 lb. capacity linear actuator with an IP66S protection rating, sealed bearings, and high-quality lubricants is a robust and versatile device designed for industrial and outdoor applications where it will be exposed to dust and water. Sealed bearings promote a long service life by preventing contaminants from entering. High-quality lubricants provide smooth operation and extended lifespan.
Standard Configurations
Capacity (lbs):
500
Stroke Length (in):
3.9, 5.9, 11.8, 17.7, 23.6
Documents
Need Assistance?
Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.
Specifications
Specifications
| Model Number | Capacity (lbs) | Duty Cycle at Rated Load (%) | Environment (IP Code) | Input Voltage (VAC) | Input Voltage (VDC) | Lifting Speed at Rated Load (in/s) | Limit Switch | Retracted Length (in) | Stroke Length (in) |
|---|---|---|---|---|---|---|---|---|---|
| 192002601 | 500 | IP66S | 115 | 0.71 | 3.9 | ||||
| 192002603 | 500 | IP66S | 115 | 0.71 | 5.9 | ||||
| 192002604 | 500 | IP66S | 115 | 0.71 | 11.8 | 11.8 | |||
| 192002605 | 500 | IP66S | 115 | 0.71 | 17.7 | ||||
| 192012291 | 500 | 115 | 0.71 | 11.8 | |||||
| 192013629 | 500 | 115 | 0.71 | 3.9 | |||||
| 192026899 | 500 | IP66S | 115 | 0.71 | 5.9 | ||||
| 192027758 | 500 | IP66S | 115 | 0.71 | 5.9 | ||||
| 192030285 | 500 | IP66S | 115 | 0.71 | 5.9 | ||||
| 192033567 | 500 | IP66S | 115 | 0.71 | 11.8 | ||||
| 192033569 | 500 | IP66S | 115 | 0.71 | 17.7 | ||||
| 192054153 | 500 | IP66S | 115 | 0.71 | 23.6 | ||||
| 192064319 | 500 | IP66S | 115 | 0.71 | 23.6 | ||||
| 192068901 | 500 | IP66S | 230 | 0.71 | 11.8 | ||||
| 192078079 | 500 | IP66S | 115 | 0.71 | 17.7 |
