SW-W Wall-mounted wire rope winch

Image manual winch SW-W-300-750kg

Image manual winch SW-W-80-125kg

Capacity: 80 - 750 kg. Intended for stationary mounting in buildings, smooth-running spur gear, direct drive for loads up to 125 kg.

Need Assistance?

Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.

Features and Benefits

SW-W
Wall-mounted winch
Capacity 80 - 750 kg

Wall-mounted rope winches of the SW-W model range are
intended for fixed stationary mounting inside a building.
The steel wire rope is guided to the required suspension
point of the load by means of deflection sheaves.

Features:
• Robust aluminium housing for models SW-W 80 and SW-W 125, proven steel plate design for models
SW-W 300 - 750.
• Spur gear drive for optimal efficiency and comfortable handling. Direct drive for loads up to 125 kg.
• The low-noise safety spring brake safely holds the load in every position.
• Removable hand crank for models SW-W 80 and SW-W 125, foldable crank for models SW-W 300 - 750.
• Easy and quick mounting onto walls.

The wall rope winches SW-W are intended for stationary installation.

Equipment and processing

Carrying loads 80- 750 kg
Robust aluminium housing for SW-W 80 and 125 kg
Tried and tested steel sheet design for rope winches 300 - 750 kg
Smoothly running spur gear for high efficiency (300 - 750 kg)
Direct drive for carrying loads up to 125 kg
Low-noise safety spring brake holds the load securely in any position
Removable hand crank for wall rope winch 80 and 125 kg
Folding crank for version 300 - 750 kg
Simple and quick attachment to walls

Pfaff-silberblau - manual and electric wire rope winches

Our wire rope winches can be used in various applications. Discover in this short clip the possibilities that our winches open up.

Pfaff-silberblau - product overview lifting and motion technology

We are technology leaders in components and system solutions for mechanical motion and lifting technology.

Our product portfolio includes #screwjacks, #linearmotion, #liftingcolumns, #liftingtables, #electric and #manuel #wireropewinches, #screws, #nuts, #bevelgear boxes and #accessories.

Contact our sales team

Columbus McKinnon Engineered Products GmbH
Am Silberpark 2-8 | 86438 Kissing | Germany

Phone Sales: +49 8233 2121- 777

sales.kissing@cmco.eu

Documents

Brochures & Catalogues

[Catalogs] Pfaff Wire Rope Winches - Catalogue English [Catalogs] Pfaff Wire Rope Winches - Catalogue Deutsch

Manuals & Supplements

[O&M Manual] Pfaff SW-W - Manuals

Product & Data Sheets

[Product Sheet] Seilwinden-Zubehör-Katseite-DE21 [Product Sheet] Pfaff-Accessoires-pour-treuils-Catpage-FR [Product Sheet] Pfaff-Accessories-Winches-EN21 [Datasheets] Pfaff SW-W - Datasheet English [Datasheets] Pfaff SW-W - Datasheet German [Product Sheet] Pfaff-SW-W-Catalogpage-FR
