SW-K LAMBDA Console-Mounted Wire Rope Winch

Capacity: 300 kg. The console-mounted wire rope SW-K LAMBDA DGUV V17/18 (BGV C1) was developed for use in shopping galleries, churches, sports facilities and performing areas (stages, studios, theaters etc.).

Need Assistance?

Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.

Features and Benefits

The console-mounted wire rope SW-K LAMBDA DGUV V17/18 (BGV C1) was developed for use in shopping galleries, churches, sports facilities and performing areas (stages, studios, theaters etc.).
Equipment and processing
Loads 300 kg
Modern design with galvanised sides for simple handling
Grooved drum for single-layer coiling of the steel rope
Long service life of the rope by 18-fold drum diameter
With spring-loaded rope pressure roller against the jump of the unstressed rope at the drum
Gearbox design for double nominal load
Smoothly running spur gear for high efficiency
Attached safety crank with two spring brakes acting independently of each other for safe hold of the load in any position
optional drum extension or special grooving possible
Options:
Drum extension for a larger rope intake
Special grooving (multiple ropes)
